卧式加工中心

TREVISAN DS200

Trevisan DS200 is a Machining Center featuring an integrated turning device (U-axis/facing head), enabling turning with the workpiece stationary and the tool rotating (cylindrical, conical, spherical, threading, facing) and, within the same setup, milling, drilling, and reaming with the main spindle. It is equipped with two independent spindles (milling head + U-axis facing head) and automatic tool change, thus functioning as a combined "lathe + machining center" in a single unit, reducing cycle times and errors due to re-clamping.

Nwjdpfx Aexrb Ukjb Hon
Typical Architecture of the DS200 Series
• Structure: bed and columns made of high-rigidity cast iron.
• Contouring head (U-axis): various diameters with a radial travel of 70 mm, multi-tool tool holder, and constant surface speed for high-quality turning with the workpiece stationary.
• Table/palletization: 1 pallet with a table size of 1200x600 mm.
• Capacities: up to Ø350 mm.

Focus on the Trevisan DS200/70
The DS200/70 belongs to the "Small/Compact" family, designed for medium-sized parts requiring precision turning and milling/drilling operations in a single setup. According to Trevisan nomenclature, “200/70” indicates a facing head diameter of 200 mm with U-axis travel of 70 mm.
Indicative Configuration and Capabilities
• Type: Trevisan DS200 turning-milling center
• Facing/contouring head (U-axis): Ø ≈ 200 mm, U-axis travel ≈ 70 mm, suitable for cylindrical, conical, spherical, threading, facing operations with the workpiece fixed.
• Basic travels (DS200/70 class): X ≈ 520 mm.
• Single-setup processes: turning (fixed workpiece) + milling/boring with main spindle → reduced cycle time and improved coaxiality between turned and machined surfaces.

Typical Use Cases
• Valve bodies, covers, flanges, and pump components where turned internal/external profiles (spherical, conical) and multiple precision drilling/milling operations are required.
