立式车床

INDEX V 300 Y/B

swing diameter max. 450 mm
chucking diameter 400 mm
control Siemens 840D (Index)
Nwsdpeyq Sk Iefx Agpeh
Max. rpm 4.200 min/-1
power capacity - main spindel ( 35,5 / 56 ) kW
max. Torque ( 340 / 550 ) Nm
C-Axis 0,001 °
number of toolpositions 2x 12 pos
driven statition 2x 12 pos
worktool system VDI 30
max. spindle speed driven tools 6.000 U/min.
power capacity - driven tools 9,5 kW
max. Torque 40%: 19 Nm
Y - Axis +/- 90 mm
B-Axis +270° / -90 °
x-axis 730 mm
z-axis 340 mm
y-axis +/- 90 mm
b-axis +270° / -90 °
rapid traverse X: 40 / Z: 30 m/min
numbers of pallets 24 pos.
size of pallet 410 x 300 mm
max. workpiecediameter 300 mm
max. workpiece weight incl. Pallet: 25 kg
Chain width 75 mm
band speed 7,5 m/min
total power requirement 56 kW
weight of the machine ca. 9,0 t
dimensions of the machine ca. 8,5 x 6,0 x 2,7 m
CNC - Vertical Lathe
INDEX - V 300 Y/B

- incl. 24 pos. palett changing system Schnaithmann
- incl. ball screw as spare part


- incl. 39x driven tools
- incl. 39x tool holders
