HawkTech HTL Series

FIELD: Machine type
Fiber Laser Cutting Machine
FIELD: Manufacturer
HawkTech/Dardontech
FIELD: Model
HTL Series (HTL3015 / HTL4020 / HTL6020 / HTL6025 / HTL8025 / DHTL12025)
FIELD: Condition
New
FIELD: Year of construction
2025

FIELD: Technical data / Description (copy the entire text below)

NEW – DS Series Fiber Laser Cutting Machine | Available in 6 models | Immediate delivery from stock
Condition: new, Year of construction: 2025, functionality: fully functional
TECHNICAL SPECIFICATIONS:

Max. processing sheet: 3,000 x 1,500 mm (DS3015) up to 12,000 x 2,500 mm (DS12025)
X axis stroke: 1,530 mm (DS3015) – 2,530 mm (DS12025)
Y axis stroke: 3,030 mm (DS3015) – 12,030 mm (DS12025)
Z axis stroke: ≤150 mm (smaller models) / ≤200 mm (DS8025, DS12025)
Max. XY speed: 120 m/min
Max. XY acceleration: 1.2 g (DS3015) – 2.5 g (DS12025)
X/Y positioning accuracy: ±0.03 mm (DS3015/DS4020) / ±0.05 mm (larger models)
X/Y re-positioning accuracy: ±0.02 mm (all models)

Ppjdpfx Aloymc Ucehou
AVAILABLE LASER POWER OPTIONS:
1 kW / 1.5 kW / 2 kW / 3 kW / 4 kW / 6 kW / 8 kW / 12 kW / 15 kW / 20 kW
MACHINE FEATURES:

Welded steel frame with high-temperature aging treatment for long-term rigidity
Gantry dual-drive structure for stable high-speed motion
Aviation-grade aluminum beam and Z-axis
High-precision rack and bilateral gear system
Concave-convex follow-up cutting head for adaptive surface tracking
Universal steel ball support table
Multiple limit protection: induction limit, hard limit, origin limit

AVAILABLE OPTIONS:

Dust collector: 4 filters (5.5 kW) / 6 filters (7.5 kW) / 8 filters (11 kW)
Stabilizer: SWF-30KVA up to SBW-150KVA

INCLUDED SERVICES:

12-month warranty
Spare parts availability
Technical support and commissioning assistance
CE documentation available upon request

Sold by HawkTech s.r.o. – certified industrial machinery dealer, Czech Republic.
Delivery to CZ, SK and EU. Price upon request.
