DMG DMC 1035 V

DMG DMC 1035 V

Machining Center DMG DMC 1035 V with Heidenhain ITNC 530 Control, Year 2007, in Excellent Original Condition
The machine comes from the toolmaking department of a renowned German mechanical engineering company.
CE compliant!!

Technical Data:

Year of manufacture: 2007
Technical Details
X-travel: 1,035 mm
Y-travel: 560 mm
Z-travel: 510 mm
Control: iTNC 530 Heidenhain
Main Spindle:

Speed Range (Main Spindle): 20 – 8,000 min⁻¹
Drive Power (Main Spindle): 13 / 9 kW

Tool Holder
BT 40
Draw Bar: ISO 7388-3-A AD40
Work Table:

Clamping Surface: 1,200 x 560 mm
Max. Table Load: 1,000 kg
Table Height above Floor: 720 mm
T-slots: 5 x 14 x 100
Tool Changer:

Number of Tool Stations: 20
Max. Tool Diameter: 80 mm
Max. Tool Diameter with free adjacent slot: 130 mm
Max. Tool Length: 300 mm
Max. Tool Weight: 6.0 kg
Tool Change Time: 1.6 sec
Chip-to-chip Time: 7.0 sec
Feeds:

Feed Rate: 24,000 mm/min
Ltodpexqgrxefx Af Dea
Rapid Traverse: 30 m/min
Connected Load: 20 kVA
Machine Weight approx.: 4.5 t
Required Installation Space approx.: 4.0 x 4.0 x 2.5 m

About the machine:

Offered here is a DMG DMC 1035 V machining center with a Heidenhain ITNC 530 control. This machining center is in excellent original condition. It comes from a facility where it was used primarily for training purposes, meaning minimal hours of operation. The control is very easy to operate. The guideways are regularly lubricated by centralized lubrication. The DMG DMC 1035 V has been mechanically and electrically inspected by us. Take the opportunity to visit and inspect the DMG DMC 1035 V under power at our premises.
