WEINIG Powermat 600 Compact

Number of spindles 5 St.
Working width 230 mm
Working height 120 mm
Length of the planing table 2500 mm
Feed motor 4 kW
Feed speed 5-30 m/min.
Control Memory-Funktion
Weinig Powermat 600 Compact
Iijdpowzmu Rsfx Af Dek

-----
The machine has been cleaned and fully inspected.

Brief Summary:
-----
- 5 Spindles
- Powerful Motors
- Left and top spindles controlled for width and height

Detailed Description:

-----

Technical Data:
Working Width: 20-230 mm
Working Height: 10-120 mm

Number of Spindles: 5

1st Spindle - Bottom
-----
Motor with brake: 7.5 kW
Spindle diameter: 40 mm
Speed: 6,000 rpm
Tool Circle: 125-145 mm
Tool Circle for Rebating Cutter: 130-160 mm
Axially Travel: 5 mm
Rebating Device
MarathonCoatine for table insert in front of the 1st lower tool holder
Electronic digital display for rotary adjustment

2nd Spindle - Right

-----
Motor with brake: 11.0 kW
Shared motor with left-hand tool holder
Spindle diameter: 40 mm
Speed: 6,000 rpm
Tool swing diameter 40 mm below table level: 93 - 200 mm
Tool swing diameter 55 mm below table level: 93 - 180 mm
Tool swing diameter for straight cutter heads max. 163 mm
Max. tool diameter behind fence: 180 mm
Max. groove depth: 35 mm
Axially travel: 55 mm

3rd Spindle - Left
-----
Motor with brake: Shared motor with the 2nd spindle
Spindle diameter: 40 mm
Speed: 6,000 rpm
Tool swing diameter 40 mm below table level: 93 - 200 mm
Tool swing diameter 55 mm below table level: 93 - 180 mm
Tool swing diameter for straight cutter heads max. 163 mm
Max. groove depth: 35 mm
Axially travel: 55 mm
CNC-controlled radial spindle

4th spindle - top
-----
Motor with brake: 11.0 kW
Spindle diameter: 40 mm
Speed: 6,000 rpm
Tool swing diameter: 93 - 200 mm
Tool swing diameter for straight cutter heads max.: 180 mm
Max. groove depth: 35 mm
Axially travel: 40 mm
CNC-controlled radial spindle

Split pressure shoe in front of upper tool holder, adjustable to the tool swing diameter and pivoting away from the tool, spring-loaded.


Pressure shoe in front of, and discharge after, the upper spindle with electronic
digital displays, integrated into the memory function or the PowerCom

5. Spindle - bottom

-----
Motor with brake: 7.5 kW
Spindle diameter: 40 mm
Speed: 6,000 rpm
Tool travel: 93 - 200 mm
Max. throat depth: 15 mm
Axially travel: 35 mm

Feed system
-----
Electronic feed, infinitely variable with brake: 4 kW, 5 - 30 m/min
Infeed roller in front of the first lower tool, pneumatically controlled up/down.

Durofer pointed tooth rollers with depth limiter and self-cleaning.

Adjustment travel of the feed rollers relative to the left tool holder, axial 35 mm

Machine electrical system

-----
Operating voltage 400 V (voltage range 380–420 V), 50 Hz.
All spindles IE2 design.
Electrical design according to DIN VDE 0113, electrical equipment of industrial machines EN 60204, IEC 204-1. Other electrical regulations are not considered.


Machine stand, tables, and ...
