角窗加工中心

SCM MULTIFLEX C

Code: 0321
Brand: SCM
Model: MULTIFLEX C - CE Standard

Automatic working center for window frames for tenoning, profiling and contouring - Max workpiece thickness mm 140 - CE Standard

Technical data
Automatic carriage with chipbreaker
Max working length 2800 mm
Min/max workpiece thickness 30/140 mm
End cutting saw diameter 400 mm - Motor Hp 4
Tenoning spindle useful length mm 320 - Motor Hp 10
Spindle diameter mm 50
Lredpfx Aljytn U Iodjk
Max tool diameter mm 350
Profiling spindles:
1° Anti-splinter profiling spindle length 320 mm - Motor Hp 7,5 - Tool diameter mm 220
2° profiling spindle length mm 320 - Motor Hp 7,5 - Tool diameter mm 220
Min and max diameter of profiling spindles tools mm 100/220
Profiling spindles diameter 50 mm
Tool group Zuani
Variable speed feed
Glazing bead recovery group - Motor Hp 3 - Diameter of suction mouth mm 50
Overall dimensions mm 2400 x 3300 x 2000 h
Weight kg 2200
