Novatec Pluritank PLT150

4-chamber ultrasonic cleaning system with automatic goods transport

Gkjdpfx Ahsy H Uzvj Esd
Maximum loading weight: 50 kg including basket
Usable basket dimensions (internal): 426 x 375 x 470h mm

Loading station with transport trolley
1. Ultrasonic cleaning with bottom and side sonication (25/45 kHz - switchable)
2. Ultrasonic rinsing with bottom sonication (25/45 kHz - switchable)
3. Ultrasonic rinsing with bottom sonication (25/45 kHz - switchable), including lift-out function
4. Hot air dryer
Unloading station

- Tank 1 (ultrasonic cleaning) is also equipped with an overflow and a large separate oil separator.
- Automatic cover on Tank 1
- Media filtration in all tanks (via cartridge filter)
- Complete system enclosed and with exhaust extraction
- Control system: Siemens S7-1500 incl. 12" HMI touch panel
- Documentation available in German

Electrical connected load: 59 kW

The system can also be dismantled and re-installed at a new location by our specialist technicians for an additional charge, if required.

Water treatment for Tank 4 (final rinse) can be supplied at extra cost.
Test cleaning possible at any time, the system is powered up.
