This Felder FORMAT 4 Tempora60.06LX edgebander was manufactured in 2019. It features an x-motion PLUS control system, chain feed with a speed of 10 m/min, and a Teflon-coated gluing unit for EVA or PUR granulate. The machine supports edge thicknesses from 0.4 to 3 mm and includes a multifunctional milling unit. Consider the opportunity to buy this Felder FORMAT 4 Tempora60.06LX edgebander. Contact us for more information about this machine.

• Control system: x-motion PLUS
• Chain feed
• Feed speed: 10 m/min
• Drive motor: 0.75 kW (S6) – 1.1 kW (S6)
• Minimum workpiece length: 140 mm
• Minimum workpiece width: 70 mm
• Note: Minimum width varies depending on workpiece length, height, and surface finish.
• Turntable edge magazine (rolled edge material)
• Turntable diameter: 750 mm
• Edge thickness: 0.4 – 3 mm
• Extendable frame
• Workpiece support extendable up to 450 mm
• Upper pressure bar
• Manually adjustable workpiece height: 8 – 60 mm
• Edge feed
• For rolls and rigid material
Gsdpfxjx D D R Sj Ad Hoir
• Joining unit
• Power: 2.2 kW (2 × 1.1 kW)
• Diamond cutter Z2
• Speed: 12,000 rpm
• Gluing unit
• Teflon-coated for 1.5 kg EVA or PUR granulate
• Ready after approx. 10 min heating time
• Tool-free quick-change system
• Pressure unit
• Pneumatically controlled
• 1 driven and 2 conical pressure rollers
• Shear
• For roll edge material thickness: 0.4 – 3 mm
• Cutting unit
• Two high-frequency motors, each 0.35 kW, 12,000 rpm
• Pneumatically swiveling 0° – 10°
• Multifunctional milling unit (x-motion PLUS)
• Flush and radius milling
• One HF motor top and bottom, each 0.75 kW, 12,000 rpm
• Each with 4 interchangeable blades
• Corner processing unit
• For soft and postforming workpieces
• Front edge processing
• Edge thickness: 0.4 – 3.0 mm
• Workpiece height: 10 – 60 mm
• Radius scraper unit
• 2-axis motor-driven, position-controlled
• Pneumatic release function
• Polishing unit
• Top and bottom
