CORMAK Łuparka do drewna LUP16T

PROFESSIONAL WOOD SPLITTER 16 TONS. The robust construction and high-quality wedge guarantees a long service life and trouble-free operation.
Gtsdeuqiq Dopfx Af Eew

The machine is designed for splitting wood up to approx. 700 mm in diameter! Its stable, robust construction ensures excellent working results.

Machine description

The splitter is equipped with an overload valve that drains oil into the tank and a powerful, trouble-free gear pump.
The tree lift system makes it easy to place heavy materials directly under the splitting wedge
5-bolt power connection
Angled wedge makes it easier for the wedge to sink into the material.

FAULTLESS HYDRAULIC PUMP!
Technical specifications
Thrust force 16 TON
Minimum wood diameter 80 mm
Maximum wood diameter 700 mm
Minimum timber length 350 mm
Maximum length of wood 1100 mm
Splitting speed (continuously adjustable) 4.6 - 14.2 cm/sec.
Return speed 6.2 cm/sec.
Wedge stroke length 948 mm
Motor power 4,5 kW
Voltage 400 V
Hydraulic tank capacity 18 l
Hydraulic pressure 27.7 MPa
Dimensions 1050 x 1550 x 2500 mm
Weight approx. 259 kg
